Cantilever Arms
Powerful extensions engineered for heavy-duty support.
Technical Specifications
Specifications
| Part No. | Discription Channel Plain | Finish | Meterial | |||
| Length | x Width | x Height | x Thick | |||
| A 1001 | 150 MM | 41 MM | 41 MM | 2.5 MM | HDG | MS |
| A 1002 | 300 MM | 41 MM | 41 MM | 2.5 MM | HDG | MS |
| A 1003 | 450 MM | 41 MM | 41 MM | 2.5 MM | HDG | MS |
| A 1004 | 600 MM | 41 MM | 41 MM | 2.5 MM | HDG | MS |
| A 1005 | 750 MM | 41 MM | 41 MM | 2.5 MM | HDG | MS |
| A 1006 | 6" | 1 - 5/8" | 1 - 5/8" | 12 G | BZP. | MS |
| A 1007 | 12" | 1 - 5/8" | 1 - 5/8" | 12 G | BZP. | MS |
| A 1008 | 18" | 1 - 5/8" | 1 - 5/8" | 12 G | BZP. | MS |
| A 1009 | 24" | 1 - 5/8" | 1 - 5/8" | 12 G | BZP. | MS |
| A 1010 | 30" | 1 - 5/8" | 1 - 5/8" | 12 G | BZP. | MS |
Cantilever Arms Manufacturer & Supplier in India
Cantilever arms are horizontal steel brackets that extend out from a wall, upright, or strut channel to support pipes, cables, ducts, and other loads at a set distance. They work like a shelf bracket, but heavier: one end fixes firmly to a vertical support, and the free end carries the load away from the wall. This keeps services neatly off the ground and lets several runs stack one above another to save space. Cantilever arms are widely used in MEP (mechanical, electrical, and plumbing) systems, cable management, and storage racking. Made from mild or stainless steel and available in many lengths and load ratings, they bolt straight onto strut channel using channel nuts. Ashish International is a cantilever arms manufacturer and exporter based in Ludhiana, India, with over 25 years of experience producing support systems built to global quality standards. The right cantilever arms keep your pipes, cables, and equipment safely supported and easy to access.
What are cantilever arms used for?
Cantilever arms are load-bearing brackets fixed at one end and left free at the other, so they can hold a load away from a wall or column. The name comes from the cantilever principle in engineering, where a beam is supported only at one end. In support systems, the fixed end bolts onto a vertical strut channel or upright, and the arm reaches out to carry pipes, trays, or shelves. Because they attach to slotted strut channel, they can be set at any height and adjusted later without re-drilling. You can see the full range of arms and matching fittings on the Ashish International products page. Cantilever arms are popular because they save floor space, keep services tidy, and make installation fast. For example, a row of cantilever arms on a single upright can support five separate pipe runs, one above the other. Cantilever arms are single-end brackets that hold pipes, cables, or shelves out from a wall or upright.
How do cantilever arms work?
Cantilever arms work by transferring the weight of a load back into a strong vertical support. The arm’s fixed end is bolted to a strut channel or upright using a spring channel nut and bolt, which grips inside the channel slot so the arm cannot slip. Sometimes a gusset or a strut bracket is added at the joint for extra strength. Because the load sits away from the support, the arm and its fixing must resist a turning force (leverage) — the further out the load, the greater the stress at the fixed end, so the arm’s size and thickness must match the weight and reach. Where the upright fixes to a steel beam, a beam clamp can hold it without drilling, and threaded rod is often used to brace or hang related supports. For example, a longer arm carrying a heavy pipe needs a deeper, stronger section than a short arm holding a light cable tray. Cantilever arms bolt into strut channel and carry loads outward, so size must match the weight and reach.
What are the different types of cantilever arms?
Cantilever arms come in several types to suit different jobs. The most common in MEP work is the strut cantilever arm — a slotted steel arm that bolts to channel and supports pipes, cables, or ducts; these are also the arms many buyers search for as Unistrut cantilever arms because they fit standard strut systems. There are also heavier cantilever rack arms, used on warehouse cantilever racking to store long items like pipes, timber, and steel sections, and cantilever steady arms, a term used for arms that hold or steady a load in place. Arms can be single-sided (loading on one side of an upright) or double-sided (loading on both), and come in different lengths and load ratings. Ashish International also produces custom fabricated arms made to a client’s exact length, load, and design. For example, a storage system for long steel bars needs deep, double-sided rack arms, while a wall pipe run needs a slotted single arm. Cantilever arm types range from slotted strut arms to heavy rack arms, in single- or double-sided designs.
Where are cantilever arms used?
Cantilever arms are used wherever loads need to be supported off the ground and away from a wall. In plumbing and fire systems, they hold pipes using channel pipe clamps and pipe hangers, keeping runs neat and accessible. In electrical work, they carry cable trays and conduit; in HVAC, they support ducts and units. In warehouses, heavy cantilever arms form racking for long, bulky goods. They are also used outdoors and in plant rooms, where uprights may be fixed down with foundation and anchor bolts for stability. You can see real installations in the Ashish International product application gallery. The common thread is stacking multiple services in a small footprint. For example, a single line of uprights with cantilever arms can carry water pipes, cables, and a duct together along a corridor. Cantilever arms support pipes, cables, ducts, and stored goods across MEP, industrial, and warehouse settings.
How to choose cantilever arms and a manufacturer?
Choosing the right cantilever arms means matching the arm to the load and trusting the maker’s quality. Start with the load and reach: a heavier load or a longer arm needs a deeper, thicker section, so confirm the safe working load for the length you need. Next, choose the material and finish — galvanized mild steel for most jobs, or stainless steel for damp or corrosive sites. Make sure the arms fit your channel system; quality cantilever arms manufacturers build to standard strut sizes so the arms are compatible with common Unistrut-type channel. Check that the maker runs a certified, quality-controlled facility and can supply the matching nuts, brackets, and industrial fasteners so you get a complete system from one source. Finally, ask whether they offer custom or white-label manufacturing if you need arms to your own design or brand. For example, buying arms and fittings from one trusted manufacturer avoids mismatched parts and site delays. Choose cantilever arms by load and reach, the right material, channel compatibility, and a quality-focused manufacturer.
Why choose Ashish International for cantilever arms?
Ashish International has manufactured and exported cantilever arms and MEP support systems for over 25 years, building products to the same standards expected from leading global brands — with the shorter lead times and value of Indian manufacturing. The company produces arms in mild and stainless steel, along with the full range of channels, brackets, clamps, and fasteners, so customers can source a complete support system from one maker. Its in-house manufacturing keeps quality tight and handles both bulk and urgent requirements. Ashish International also offers white-label and OEM production, making cantilever arms to a client’s own design and brand under strict NDA — a service trusted by many long-standing customers, several with more than 20 years of association. Its products are also sold under its own brand, FITSTRUTS®. With exports to Europe, the UK, the USA, Australia, the Middle East, and beyond, the company pairs global quality with competitive Indian pricing. You can learn more about Ashish International and its experience. For example, OEM clients rely on it to protect their designs while delivering consistent, high-grade arms. Ashish International offers global-standard cantilever arms, a full product range, and trusted white-label manufacturing.
Need cantilever arms in the right length, load rating, and finish for your project? Ashish International manufactures a complete range in mild and stainless steel, with custom and white-label options. Contact our team and request a quote today — call +91-99888-54380 or email ashishint2001@gmail.com.
Frequently Asked Questions
Q1: What are cantilever arms used for?
Cantilever arms support pipes, cable trays, ducts, and stored goods out from a wall or upright. They are common in MEP systems, cable management, HVAC, and warehouse racking, where they keep services off the ground and easy to reach.
Q2: How do cantilever arms attach to strut channel?
The arm’s fixed end bolts onto slotted strut channel or an upright using a spring channel nut and bolt that grip inside the channel slot. This lets the arm be set at any height and adjusted later without re-drilling.
Q3: What is the difference between cantilever arms and cantilever rack arms?
Standard cantilever arms are MEP brackets used to support pipes, cables, and ducts.
Cantilever rack arms are heavier-duty arms used in warehouse cantilever racking systems to store long materials such as pipes, timber, and steel sections.
Q4: Are your cantilever arms compatible with Unistrut-type channel systems?
Yes. Ashish International manufactures cantilever arms to standard strut channel sizes, making them compatible with common Unistrut-type channel systems. Share your channel size and load requirements to get the right match.
Q5: Can you manufacture custom or white-label cantilever arms?
Yes. Ashish International offers OEM and white-label manufacturing services. Cantilever arms can be produced according to the client’s required length, load rating, design, and branding under NDA, with full protection of customer intellectual property.
